Product Details
Product Parameters
| Contact Form | Form A | ||||||||||||
| Switching Power (Max.) Maximum switching power | 10 | IN | |||||||||||
| Switching Voltage DC (Max.) Maximum switching voltage | 400 | In | |||||||||||
| Switching Current (Max.) Maximum switching current | 0.5 | A | |||||||||||
| Carry Current DC (Max.) Maximum load current | 1 | A | |||||||||||
| Breakdown Voltage (Min.) Minimum breakdown voltage | 350 450（PI ≥ 15） | In | |||||||||||
| Contact Resistance (Initial Max.) Maximum initial contact resistance | 0.15 | Oh | |||||||||||
| Contact Capacitance (Max.) Maximum contact capacitance | 0.7 | pF | |||||||||||
| Insulation Resistance (Min.) Minimum insulation resistance | 1010 | Oh | |||||||||||
| Operating Temperature Range | -40℃ ~ 125℃ | ℃ | |||||||||||
